The spectrum of Apert syndrome: phenotype, particularities in orthodontic treatment, and characteristics of orthognathic surgery
Head & Face Medicine volume 3, Article number: 10 (2007)
In the PubMed accessible literature, information on the characteristics of interdisciplinary orthodontic and surgical treatment of patients with Apert syndrome is rare. The aim of the present article is threefold: (1) to show the spectrum of the phenotype, in order (2) to elucidate the scope of hindrances to orthodontic treatment, and (3) to demonstrate the problems of surgery and interdisciplinary approach.
Children and adolescents who were born in 1985 or later, who were diagnosed with Apert syndrome, and who sought consultation or treatment at the Departments of Orthodontics or Craniomaxillofacial Surgery at the Dental School of the University Hospital of Münster (n = 22; 9 male, 13 female) were screened. Exemplarily, three of these patients (2 male, 1 female), seeking interdisciplinary (both orthodontic and surgical treatment) are presented. Orthodontic treatment before surgery was performed by one experienced orthodontist (AH), and orthognathic surgery was performed by one experienced surgeon (UJ), who diagnosed the syndrome according to the criteria listed in OMIM™.
In the sagittal plane, the patients suffered from a mild to a very severe Angle Class III malocclusion, which was sometimes compensated by the inclination of the lower incisors; in the vertical dimension from an open bite; and transversally from a single tooth in crossbite to a circular crossbite. All patients showed dentitio tarda, some impaction, partial eruption, idopathic root resorption, transposition or other aberrations in the position of the tooth germs, and severe crowding, with sometimes parallel molar tooth buds in each quarter of the upper jaw.
Because of the severity of malocclusion, orthodontic treatment needed to be performed with fixed appliances, and mainly with superelastic wires. The therapy was hampered with respect to positioning of bands and brackets because of incomplete tooth eruption, dense gingiva, and mucopolysaccharide ridges. Some teeth did not move, or moved insufficiently (especially with respect to rotations and torque) irrespective of surgical procedures or orthodontic mechanics and materials applied, and without prognostic factors indicating these problems. Establishing occlusal contact of all teeth was difficult. Tooth movement was generally retarded, increasing the duration of orthodontic treatment. Planning of extractions was different from that of patients without this syndrome.
In one patient, the sole surgical procedure after orthodontic treatment with fixed appliances in the maxilla and mandible was a genioplasty. Most patients needed two- jaw surgery (bilateral sagittal split osteotomy [BSSO] with mandibular setback and distraction in the maxilla). During the period of distraction, the orthodontist guided the maxilla into final position by means of bite planes and intermaxillary elastics.
To our knowledge, this is the first article in the PubMed accessible literature describing the problems with respect to interdisciplinary orthodontic and surgical procedures. Although the treatment results are not perfect, patients undergoing these procedures benefit esthetically to a high degree.
Patients need to be informed with respect to the different kinds of extractions that need to be performed, the increased treatment time, and the results, which may be reached using realistic expectations.
Apert syndrome, which was well described by a number of authors earlier [1, 2] is a rare congenital anomaly, appearing with a frequency of 1 in 55,000 to 90,909 live births [1, 3, 4] is one of the five craniosynostosis syndromes caused by allelic mutations of the fibroblast growth-factor receptor 2 (FGFR2) .
Externally, this progessive disease of growth is characterized by acrocephaly, syndactyly, and typical features in the orofacial region .
The lips are crossbow-shaped or trapezoidal, and the lower lip may seem to protrude .
The midface is retruded, which is already marked at birth . The Class III discrepancy is progressive , the maxilla is hypoplastic  in all three dimensions,  and anteriorly there is edge-to-edge contact or an open bite [8, 11, 12].
Cephalometrically, a common craniofacial asymmetry can be diagnosed . Maxillary height is extremely short, and upper facial height markedly reduced, whereas total facial height is increased as compared with the norm .
The teeth are crowded , and there is a mean dental developmental delay of 0.96 years, with a range of 0.5 to 2.9 years . The delayed eruption may be secondary to the crowding, stacking, and displacement of the teeth within the alveolus, which is often wide to accommodate the tooth buds in two rows . A primary defect in tooth eruption secondary to the "mesenchymal disorder" in Apert syndrome also must be considered .
In the mandible, thickening of the gingiva and delayed eruption are also observed, but to a lesser degree .
There are bulbous lateral swellings in the palate, which until now were not properly named in the anatomic nomenclature  and which might be so prominent that they become a food trap . This posterior notching  could suggest a cleft palate , but is actually a pseudo cleft palate. A true cleft palate occurs in 23.5% of the cases . A cleft soft palate or bifid uvula may be present in approximately 75% of the patients .
The morphological defects may induce functional defects, such as sleep apnea, disturbances of breathing, feeding, speech , and lip closure .
Despite the intrasyndromic similarities, there is a high degree of variable phenotypical expression [4, 10, 18].
The aim of the present case study is to show
the clinical variablity of Apert syndrome (spectrum of the phenotype),
implications for hindrances in orthodontic therapy, and
characteristics of surgery and interdisciplinary treatment approach.
Table 1 gives an overview of the general treatment concept for patients with Apert syndrome at the University Hospital of Münster, which allows for individual adaptions.
This paper refers to treatment stages 3 to 5 given in Table 1.
Children and adolescents who were born in 1985 or later, who were diagnosed with Apert syndrome, and who sought consultation or treatment at the Department of Orthodontics or Craniomaxillofacial Surgery at the Dental School of the University Hospital of Münster (n = 22; 9 male, 13 female) were screened.
Exemplarily, three of these patients (2 male, 1 female), seeking interdisciplinary (both orthodontic and surgical treatment) were chosen because their malocclusions were representative of the whole clinical spectrum of Apert syndrome and their treatment at stages 3–5 (Table 1) thus covered the whole therapeutic spectrum, ranging from orthodontic treatment and genioplasty only to two-jaw surgery with distraction (Table 2). Orthodontic treatment of these patients was performed by one experienced orthodontist (AH); orthognathic surgery was executed by one experienced surgeon (UJ), who diagnosed the syndrome according to the criteria listed in Online Mendelian Inheritance in Man .
History (treatment stages 1 and 2 according to Table 1):
< Age 3.0: (Surgical) treatment alieno loco.
Age 6.2: LeFort III surgery and protraction mask.
The treatment sequence is illustrated in figures 1, 2, 3, 4, 5, 6, 7, 8.
History (treatment stages 1 and 2 according to Table 1):
< Age 7.0: Surgical treatment alieno loco.
Age 7.2: Frontal advancement and protraction mask coincident with orthodontic extrusion of 11 and 21.
The treatment sequence is illustrated in figures 9, 10, 11, 12, 13, 14.
History (treatment stages 1 and 2 according to Table 1):
< Age 8.5: (Surgical) treatment alieno loco
Age 8.5: LeFort II and face mask.
The treatment sequence is illustrated in figures 15, 16, 17, 18, 19, 20, 21, 22, 23.
Discussion of exemplarily chosen cases
Although transposition of teeth 22 and 23 was accepted and torque of teeth 21 and 23 and occlusal contact of the right premolars could not be established, the patient was reported to have benefited considerably from the orthodontic treatment, both esthetically and functionally. Despite long distances for the teeth to move and 3 years of treatment, no root resorptions developed.
Thirty-six months' treatment was quite long as compared with nonsyndromic patients, nevertheless quite short considering the severity of the initial malocclusion. In case reports on Apert syndrome, Gugny [21, 22] reported a treatment time of 33 months (with further treatment with fixed appliances advised); Rynearson  treated a patient with Crouzon syndrome for 58 months; and Matsumoto et al.  reported a treatment time of 10 years. In contrast to the present case, where an upper anterior tooth was transposed, Rynearson's patient came out with a more perfect result (having only one tooth in crossbite), which was achieved with a multisegmental LeFort I osteotomy (i.e., a surgical setup) and 61 % more orthodontic treatment time . Gugny's result, after 33 months of orthodontic treatment, showed residual spaces, rotations, midline deficiency and crossbite [21, 22]; nevertheless, the improvements of the initial malocclusion were great.
The need for extractions in patients with Apert syndrome is described in various articles [21–23, 25]. The teeth selected for extraction, however were different from the present case, where unerupted canines were extracted: Gugny [21, 22] and Gugny and Vi Fane  decided to extract the upper lateral incisors and premolars in cases, where the canines already had erupted; Rynearson  extracted one premolar and several molars, but in his patient with Crouzon syndrome, too, the canines already had erupted.
In 1991, Ferraro  pointed out that certain patients with Apert syndrome might benefit from genioplasty to provide an orthognathous appearance, which has been proved by the present case.
An alternative to the practised compensating orthodontic treatment with genioplasty would have been surgical correction of the open bite. This might have reduced the total treatment time, but would have increased the patient's surgical risks.
The hand deformity and the decrease in arm mobility made it difficult to floss–even brush the teeth  which might explain the difficulties in maintaining oral hygiene. Another reason might be inanition due to the extended treatment time.
Practising orthodontic treatment phased to orthognathic surgery implies the risk of relapse and thus the need for grinding prior to surgery in patients who do not wear their retainers properly, but phasing orthodontic treatment to orthoganthic surgery might have psychologic benefits.
Orthognathic surgery implies certain risks, but it is sometimes necessary to improve a patient's appearance and social adjustment .
Problems in maintaining oral hygiene were comparable with those of case 1, probably for the same reasons.
Also comparable with case 1, case 2 also involved problems in establishing correct torque. Additional problems with lack of rotation of teeth and decelerated tooth mobility in general made the orthodontic treatment of case 2 more difficult, and led to a more compromised result as compared with case 1.
Treatment of case 2, like that of case 1 and for the same reasons, required other than the "traditional" extraction decisions.
For a discussion of the suggested orthognathic surgery, see case 3.
Initial tooth positions of case 3 were better than in cases 1 and 2. Orthodontic correction of the crossbite on the left side was impossible because of lack of possible anchors (primary absence of 21 after need for extraction due to idiopathic root resorption and additional idiopathic resorption of 24 and 25, prohibiting inclusion of these teeth into the appliance).
We agree with other authors that in patients with Apert syndrome, midface advancement will almost always be required, and repeat cranial surgery is usually necessary [7, 17]. Midfacial surgery is also best postponed as long as possible, but many children require surgery at around 4 to 6 years of age . Early midface advancement has anatomic and psychologic benefits  as well as functional advantages such as reduction of sleep apnea [27, 28]. However, the earlier midface surgery is performed, the more likely it is that further operations will be needed . Meazzini et al.  described in a cephalometric study that, after LeFort III osteotomy at younger than 10 years, the stability of the maxillary segment was remarkable with neither detrimental nor beneficial effects on subsequent growth. The authors concluded that the standard LeFort III osteotomy in childhood is a stable and effective–but generally not definitive–procedure. We do agree with that, i.e. to our experience an early LeFort III osteotomy implies the advantage to avoid a (second) LeFort III osteotomy in adolescence, but does not avoid a second osteotomy in general.
The lack of relapse and forward growth of the maxilla after surgery at younger than 10 years as described by Meazzini et al.  has been confirmed in a study by Fearon . This author speculates, that after halo distraction, most patients will likely avoid the traditional second LeFort III.
Technically difficult transpositions, involving craniosynostosis in particular, can be treated much more successfully by means of distraction osteogenesis because of bypassing the limitations of the covering soft tissues and the need for osseous transplants, resulting in the capacity for larger movements [27, 29]. Distraction osteogenesis has some further advantages, such as fewer hazardous complications, less scarring, and fewer bone defects .
To solve the dilemma of either the forward mobilization of the upper part of the midface being insufficient when one focuses on the final occlusion, or the occlusion being unsatisfactory when forward mobilization of the upper midface is sufficient, Satoh et al.  has proposed a dual distraction osteogenesis. This involves separating the midface into two portions and conducting the movements separately in the upper and lower segments in different amounts and vectors by means of internal and external distraction devices. A known problem with distraction of the midface attributed to incomplete osteotomy and muscular influence is not a linear translatory advancement, but a complex three-dimensional displacement . Thus, in contrast to a "traditional" distraction osteogenesis, the dual distraction osteogenisis proposed by Satoh at al.  only seems to exaggerate this problem.
If a mandibular setback is planned, special care must be taken to avoid significantly decreasing the airway volume, as this surgical procedure might trigger obstructive sleep apnea pre-existing in patients without Apert syndrome [33, 34].
General aspects and summary of all cases
Despite intrasyndromic similarities, the phenotypical expression in patients with Apert syndrome is highly variable [4, 10]. This clinical variability  requires creativity, both in treatment planning and treatment progress. The care offered by a multidisciplinary team [5, 7, 17, 22] is indispensable.
Tooth eruption and tooth movement of all patients was decelarated in general. Despite various orthodontic and surgical measures, some teeth moved insufficiently or not at all. Ferraro  has already pointed out that tooth eruption might be decelerated secondarily to the "mesenchymal disorder" of Apert syndrome. Periodontal fibers might suffer from a disturbance in their reaction potential.
We do agree with Ferraro , that orthopedic devices for class III malocclusions will not work in patients with Apert syndrome. The same applies to palatal expension, which requires to be surgically assisted.
With the present article, problems with respect to orthodontic and surgical procedures and interdisciplinary approach in patients with Apert syndrome are described for the first time.
Orthodontic treatment of patients with Apert syndrome is possible, and under reasonnable conditions. The outcome of interdisciplinary treatment – which is indispensable – might not necessarily be either normal appearance or function but the achievement of the best appearance and highest level of function possible.
Patients need to be informed about (1) the different kinds of extractions that might be necessary, (2) the increased treatment time, and (3) a realistic expectation of results.
Cohen MM: Apert syndrome, not Apert's syndrome: Apert neither had nor owned the syndrome that bears his name. Plast Reconstr Surg. 1997, 100: 532-533.
Wheaton SW: Two specimens of congenital cranial deformity in infants associated with fusion of fingers and toes. Trans Pathol Soc Lond. 1894, 45: 238-241.
Tolarova MM, Harris JA, Ordway DE, Vargervik K: Birth prevalence, mutation rate, sex ratio, parents' age, and ethnicity in Apert syndrome. Am J Med Genet. 1997, 72: 394-398. 10.1002/(SICI)1096-8628(19971112)72:4<394::AID-AJMG4>3.0.CO;2-R.
Arroyo Carrera I, Martinez-Frias ML, Marco Perez JJ, Paisan Grisolia L, Cardenes Rodriguez A, Nieto Conde C, Felix Rodriguez V, Egues Jimeno JJ, Morales Fernandez MC, Gomez-Ullate Vergara J, Pardo Romero M, Penas Valiente A, Olivan del Cacho MJ, Lara Palma A: Apert syndrome: clinico-epidemiological analysis of a series of consecutive cases in Spain. An Esp Pediatr. 1999, 51: 667-672.
Ibrahimi OA, Chiu ES, McCarthy JG, Mohammadi M: Understanding the molecular basis of Apert syndrome. Plast Reconstr Surg. 2005, 115: 264-270.
Paravatty RP, Ahsan A, Sebastian BT, Pai KM, Dayal PK: Apert syndrome: a case report with discussion of craniofacial features. Quintessence Int. 1999, 30: 423-426.
Ferraro NF: Dental, orthodontic, and oral/maxillofacial evaluation and treatment in Apert syndrome. Clin Plast Surg. 1991, 18: 291-307.
Renier D, Lajeunie E, Arnaud E, Marchac D: Management of craniosynostoses. Childs Nerv Syst. 2000, 16: 645-658. 10.1007/s003810000320.
Meazzini MC, Mazzoleni F, Caronni E, Bozzetti A: LeFort III advancement osteotomy in the growing child affected by Crouzon's and Apert's syndromes: presurgical and postsurgical growth. J Craniofac Surg. 2005, 16: 369-377. 10.1097/01.SCS.0000157201.81438.31.
Kreiborg S, Cohen MM: Is craniofacial morphology in Apert and Crouzon syndromes the same?. Acta Odontol Scand. 1998, 56: 339-341. 10.1080/000163598428275.
Kreiborg S, Aduss H, Cohen MM: Cephalometric study of the Apert syndrome in adolescence and adulthood. J Craniofac Genet Dev Biol. 1999, 19: 1-11.
Batra P, Duggal R, Parkash H: Dentofacial characteristics in Apert syndrome: a case report. J Indian Soc Pedod Prev Dent. 2002, 20: 118-123.
Cohen MM, Kreiborg S: A clinical study of the craniofacial features in Apert syndrome. Int J Oral Maxillofac Surg. 1996, 25: 45-53. 10.1016/S0901-5027(96)80011-7.
Kaloust S, Ishii K, Vargervik K: Dental development in Apert syndrome. Cleft Palate Craniofac J. 1997, 34: 117-121. 10.1597/1545-1569(1997)034<0117:DDIAS>2.3.CO;2.
Hohoff A, Rabe H, Ehmer U, Harms E: Palatal development of preterm and low birthweight infants compared to term infants – What do we know? Part 1: The palate of the term newborn. Head Face Med. 2005, 1: 8-10.1186/1746-160X-1-8.
Kreiborg S, Cohen MM: The oral manifestations of Apert syndrome. J Craniofac Genet Dev Biol. 1992, 12: 41-48.
Bruce DA: Consensus: craniofacial synostoses. Apert and Crouzon syndromes. Childs Nerv Syst. 1996, 12: 734-736. 10.1007/BF00366159.
Lajeunie E, Cameron R, El Ghouzzi V, de Parseval N, Journeau P, Gonzales M, Delezoide AL, Bonaventure J, Le Merrer M, Renier D: Clinical variability in patients with Apert's syndrome. J Neurosurg. 1999, 90: 443-447.
Online Mendelian Inheritance in Man. [http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=OMIM]
Wiechmann D, Ehmer U, Joos U, Dorr-Neudeck K: A prefabricated, calibrated double-base procedure-KDMMS. For the simulation and 3-dimensional planning using an articulator in orthognathic surgery. Rev Stomatol Chir Maxillofac. 1997, 98: 91-95.
Gugny PJ: Orthodontic treatment of a case of Apert's syndrome first steps towards surgical correction. Trans Eur Orthod Soc. 1973, 353-359.
Gugny P: Orthodontic participation in the treatment of a case of Apert syndrome. Orthod Fr. 1974, 45: 565-573.
Rynearson RD: Case report: orthodontic and dentofacial orthopedic considerations in Apert's syndrome. Angle Orthod. 2000, 70: 247-252.
Matsumoto K, Nakanishi H, Koizumi Y, Seike T, Okazaki M, Yokozeki M, Moriyama K: Segmental distraction of the midface in a patient with Crouzon syndrome. J Craniofac Surg. 2002, 13: 273-278. 10.1097/00001665-200203000-00015.
Gugny P, ViFane B: Current aspects of orthodontic treatment of craniofacial stenoses. Orthod Fr. 1988, 59 (Pt 2): 635-645.
Sarimski K: Social adjustment of children with a severe craniofacial anomaly (Apert syndrome). Child Care Health Dev. 2001, 27: 583-590. 10.1046/j.1365-2214.2001.00224.x.
Weingart D, Roser M, Lantos P: Mid-face distraction after LeFort III osteotomy in craniofacial dysmorphism. Mund Kiefer Gesichtschir. 2001, 5: 221-226.
Fearon JA: Halo distraction of the LeFort III in syndromic craniosynostosis: a long-term assessment. Plast Reconstr Surg. 2005, 115: 1524-1536. 10.1097/01.PRS.0000160271.08827.15.
Meling TR, Due-Tonnessen BJ, Hogevold HE, Skjelbred P, Arctander K: Monobloc distraction osteogenesis in pediatric patients with severe syndromal craniosynostosis. J Craniofac Surg. 2004, 15: 990-1001. 10.1097/00001665-200411000-00020.
Yano H, Tanaka K, Sueyoshi O, Takahashi K, Hirata R, Hirano A: Cranial vault distraction: its illusionary effect and limitation. Plast Reconstr Surg. 2006, 117: 193-201. 10.1097/01.prs.0000194903.45939.b8.
Satoh K, Mitsukawa N, Hosaka Y: Dual midfacial distraction osteogenesis: LeFort III minus I and LeFort I for syndromic craniosynostosis. Plast Reconstr Surg. 2003, 111: 1019-1028. 10.1097/01.PRS.0000047440.06788.72.
Lippold C, Danesh G, Meyer U, Hohoff A, Kelker M, Kleinheinz J: Potential and limitations of cephalometric analysis of maxillofacial bone movement in the case of LeFort III-distraction. J Orofac Orthop. 2005, 66: 388-396. 10.1007/s00056-0510-8.
Guilleminault C, Riley R, Powell N: Sleep apnea in normal subjects following mandibular osteotomy with retrusion. Chest. 1985, 88: 776-778.
Riley RW, Powell NB, Guilleminault C, Ware W: Obstructive sleep apnea syndrome following surgery for mandibular prognathism. J Oral Maxillofac Surg. 1987, 45: 450-452.
Powiertowski H: Surgery of craniosynostosos in avanced cases. Advances and technical standards in neurosurgery. Edited by: Krayenbühl H. 1974, Wien, New York: Springer, 91-
We thank our patients and their parents for consenting to publication of their cases.
The author(s) declare that they have no competing interests.
AH performed the orthodontic treatment, conceived the necessity for publication, and drafted the manuscript. UJ performed the surgery. UM was responsible for the distraction protocol. UJ, UM, UE, and TS revised the manuscript critically for important intellectual content. All authors read and approved the final manuscript.
Ariane Hohoff, Ulrich Joos, Ulrich Meyer, Ulrike Ehmer and Thomas Stamm contributed equally to this work.
