Solitary submucous neurofibroma of the mandible: review of the literature and report of a rare case

  • Rita Depprich1,

    Affiliated with

    • Daman D Singh1Email author,

      Affiliated with

      • Petra Reinecke2,

        Affiliated with

        • Norbert R Kübler1 and

          Affiliated with

          • Jörg Handschel1

            Affiliated with

            Head & Face Medicine20095:24

            DOI: 10.1186/1746-160X-5-24

            Received: 23 September 2009

            Accepted: 13 November 2009

            Published: 13 November 2009

            Abstract

            Solitary neurofibroma is a rare benign non-odontogenic tumor. Particularly in the oral cavity, neurogenic tumors are rare, especially if they are malignant. Neurofibromas may present either as solitary lesions or as part of the generalised syndrome of neurofibromatosis or von Recklinghausen's disease of the skin. Clinically, oral neurofibromas usually appear as pediculated or sessile nodules, with slow growth and mostly without pain. The diagnosis can be confirmed by histological examination. Neurofibromas are immunopositive for the S-100 protein, indicating its neural origin. Treatment is surgical and the prognosis is excellent. For illustration a rare case of a solitary neurofibroma in the mandible is presented.

            Introduction

            Neurogenic tumors are rare in the oral cavity, particularly so when malignant. Traumatic neuroma, although usually included with neurogenic tumors, is a reactive process rather than a true neoplasm [1]. In contrast, neurofibroma and schwannoma derive from nerve fibers, the perineurium, the endoneurium and the neurolemmomal cells [1]. Neurofibromas may present either as solitary lesions or as part of the generalised syndrome of neurofibromatosis or von Recklinghausen's disease of the skin [48]. Since the first description of solitary neurofibroma (neurilemmoma, schwannoma) of the oral cavity in 1954 by Bruce only few cases have been reported in the literature [2].

            Epidemiology

            Although neurofibroma represents one of the most common neurogenic tumors it is an uncommon intraoral tumor [3] like some other intraoral tumours [4]. Neurofibromas can be multiple or solitary. The tumor's most frequent location is the skin and its multiple appearance is highly associated with von Recklinghausen's disease and poliglandular syndrome MEN III [59]. It mainly appears in the third decade of life although occurrence between 10 months and 70 years old has been described. Any preference of sex is reported contradictorily [6]. There are no correlations reported with immunocompromising diseases [10].

            Clinical features

            Clinically, oral neurofibromas usually appear as pediculated or sessile nodule, with slow growth. They are usually painless, but pain or paresthesia may occur due to nervous compression. The most frequent location is the tongue, although they may occur at any site, especially on the palate, cheek mucosa and floor of the mouth [1, 1114]. Even intraosseous location of the mandible has been described [1518]. The definitive diagnosis is due to histological examination.

            Pathohistological features

            The macroscopic appearance of the oral neurofibroma is characterized by a whitish consistent mass with shiny surface. Microscopically the tumor is composed of an irregular pattern of proliferative spindle cells. The stroma is composed of collagen fibers and mucoid masses. Small axons all over the tumoral tissue are demonstrated with silver staining. Neurofibromas are immunopositive for the S-100 protein in 85 to 100% of the cases, indicating its neural origin [1923].

            Treatment and prognosis

            Treatment of choice is surgical excision of the solitary lesions, trying to conserve the nerve from which the tumor originates [5]. Malignant transformation of solitary neurofibroma is extremely rare. Recurrence is also rare although some authors suggest higher rate of recurrence at head and neck location of solitary neurofibromas [2428]. Therefore, the prognosis is quite excellent.

            Case report

            A 64-year-old male patient with a history of somewhat alcohol but no nicotine or any other diseases attended the department for Cranio- and Maxillofacial Surgery. Clinical examination revealed an exophytic tumor in the oral cavity extending all along the lingual aspect of the left mandible (fig. 1). Panoramic radiographs showed little to moderate interdental loss of bone between teeth 37 and 38 but no other abnormalities. Several biopsies from the oral cavity revealed a submucous benign mesenchymale proliferation with no signs of malignancy and thus, the tumor was completely excised under general anaesthesia (fig. 2, fig. 3). Surgical treatment also included extraction of teeth 37 and 38 and a modelling osteotomie. Immunohistochemical findings showed a solitary submucous neurofibroma with a predominate fibromatous component (fig. 4).
            http://static-content.springer.com/image/art%3A10.1186%2F1746-160X-5-24/MediaObjects/13005_2009_Article_159_Fig1_HTML.jpg
            Figure 1

            Preoperative view: an exophytic tumor extending all along the lingual aspect of the left mandible.

            http://static-content.springer.com/image/art%3A10.1186%2F1746-160X-5-24/MediaObjects/13005_2009_Article_159_Fig2_HTML.jpg
            Figure 2

            Tumor mass after resection.

            http://static-content.springer.com/image/art%3A10.1186%2F1746-160X-5-24/MediaObjects/13005_2009_Article_159_Fig3_HTML.jpg
            Figure 3

            Histological findings showing a tumor of proliferative spindle cells with a stroma composed of irregular collagen fibers (HE, × 100).

            http://static-content.springer.com/image/art%3A10.1186%2F1746-160X-5-24/MediaObjects/13005_2009_Article_159_Fig4_HTML.jpg
            Figure 4

            Immunopositive staining for the S-100 protein (×320).

            In the presenting case the lesion occured at the lingual site of the left mandible presenting as painless pediculated exophytic tumor with slow growth. The localisation supports the lingual nerve as origin for the neurofibroma. The patient presented no signs of von Recklinghausen disease or poliglandular syndrome. Preoperative panoramic radiographs showed no serious abnormalities. Definitive diagnosis was based upon histological and inmunohistochemical findings. A clinical follow-up has been regularly performed for one year, there was no evidence of recurrence until now.

            Declarations

            Authors’ Affiliations

            (1)
            Department for Cranio- and Maxillofacial Surgery, Heinrich-Heine-University
            (2)
            Department for Pathology, Heinrich-Heine-University

            References

            1. Zachariades N, Mezitis M, Vairaktaris E, Triantafyllou D, Skoura-Kafoussia C, Konsolaki-Agouridaki E, Hadjiolou E, Papavassiliou D: Benign neurogenic tumors of the oral cavity. Int J Oral Maxillofac Surg 1987, 16:70–76.View ArticlePubMed
            2. Bruce KW: Solitary neurofibroma (neurilemmoma, schwannoma) of the oral cavity. Oral Surg Oral Med Oral Pathol 1954, 7:1150–1159.View ArticlePubMed
            3. Boedeker CC, Ridder GJ, Kayser G, Schipper J, Maier W: Solitary neurofibroma of the maxillary sinus and pterygopalatine fossa. Otolaryngol Head Neck Surg 2005, 133:458–459.View ArticlePubMed
            4. Handschel J, Herbst H, Brand B, Meyer U, Piffko J: Intraoral sebaceous carcinoma. Br J Oral Maxillofac Surg 2003, 41:84–87.View ArticlePubMed
            5. Alatli C, Oner B, Unur M, Erseven G: Solitary plexiform neurofibroma of the oral cavity A case report. Int J Oral Maxillofac Surg 1996, 25:379–380.View ArticlePubMed
            6. Gomez-Oliveira G, Fernandez-Alba Luengo J, Martin-Sastre R, Patino-Seijas B, Lopez-Cedrun-Cembranos JL: Plexiform neurofibroma of the cheek mucosa. A case report. Med Oral 2004, 9:263–267.PubMed
            7. Badger GR: Solitary neurofibromatosis in the maxilla: report of oral findings. J Am Dent Assoc 1980, 100:213–214.PubMed
            8. Che Z, Nam W, Park WS, Kim HJ, Cha IH, Kim HS, Yook JI, Kim J, Lee SH: Intraosseous nerve sheath tumors in the jaws. Yonsei Med J 2006, 47:264–270.View ArticlePubMed
            9. Guneri EA, Akoglu E, Sutay S, Ceryan K, Sagol O, Pabuccuoglu U: Plexiform neurofibroma of the tongue: a case report of a child. Turk J Pediatr 2006, 48:155–158.PubMed
            10. Meyer U, Kleinheinz J, Handschel J, Kruse-Losler B, Weingart D, Joos U: Oral findings in three different groups of immunocompromised patients. J Oral Pathol Med 2000, 29:153–158.View ArticlePubMed
            11. Richards D: Neurofibroma of the oral cavity. Br J Oral Surg 1983, 21:36–43.View ArticlePubMed
            12. Shimoyama T, Kato T, Nasu D, Kaneko T, Horie N, Ide F: Solitary neurofibroma of the oral mucosa: a previously undescribed variant of neurofibroma. J Oral Sci 2002, 44:59–63.PubMed
            13. Sinha R, Paul R, Sen I, Sikdar B: A solitary huge neurofibroma of the soft palate. J Laryngol Otol 2002, 116:637–638.View ArticlePubMed
            14. Skouteris CA, Sotereanos GC: Solitary neurofibroma of the maxilla: report of a case. J Oral Maxillofac Surg 1988, 46:701–705.View ArticlePubMed
            15. Vivek N, Manikandhan R, James PC, Rajeev R: Solitary intraosseous neurofibroma of mandible. Indian J Dent Res 2006, 17:135–138.View ArticlePubMed
            16. Ueda M, Suzuki H, Kaneda T: Solitary intraosseous neurofibroma of the mandible: report of a case. Nagoya J Med Sci 1993, 55:97–101.PubMed
            17. Apostolidis C, Anterriotis D, Rapidis AD, Angelopoulos AP: Solitary intraosseous neurofibroma of the inferior alveolar nerve: report of a case. J Oral Maxillofac Surg 2001, 59:232–235.View ArticlePubMed
            18. Sigillo R, Rivera H, Nikitakis NG, Sauk JJ: Neurofibromatosis type 1: a clinicopathological study of the orofacial manifestations in 6 pediatric patients. Pediatr Dent 2002, 24:575–580.PubMed
            19. Fisher DA, Chu P, McCalmont T: Solitary plexiform neurofibroma is not pathognomonic of von Recklinghausen's neurofibromatosis: a report of a case. Int J Dermatol 1997, 36:439–442.View ArticlePubMed
            20. Johnson MD, Glick AD, Davis BW: Immunohistochemical evaluation of Leu-7, myelin basic-protein, S100-protein, glial-fibrillary acidic-protein, and LN3 immunoreactivity in nerve sheath tumors and sarcomas. Arch Pathol Lab Med 1988, 112:155–160.PubMed
            21. Weiss SW, Langloss JM, Enzinger FM: Value of S-100 protein in the diagnosis of soft tissue tumors with particular reference to benign and malignant Schwann cell tumors. Lab Invest 1983, 49:299–308.PubMed
            22. Depprich R, Handschel J, Sebald W, Kubler NR, Wurzler KK: [Comparison of the osteogenic activity of bone morphogenetic protein (BMP) mutants]. Mund Kiefer Gesichtschir 2005, 9:363–368.View ArticlePubMed
            23. Handschel JG, Depprich RA, Dirksen D, Runte C, Zimmermann A, Kubler NR: A prospective comparison of octyl-2-cyanoacrylate and suture in standardized facial wounds. Int J Oral Maxillofac Surg 2006, 35:318–323.View ArticlePubMed
            24. Wise JB, Patel SG, Shah JP: Management issues in massive pediatric facial plexiform neurofibroma with neurofibromatosis type 1. Head Neck 2002, 24:207–211.View ArticlePubMed
            25. Polak M, Polak G, Brocheriou C, Vigneul J: Solitary neurofibroma of the mandible: case report and review of the literature. J Oral Maxillofac Surg 1989, 47:65–68.View ArticlePubMed
            26. Takahama A Jr, Leon JE, de Almeida OP, Kowalski LP: Nonlymphoid mesenchymal tumors of the parotid gland. Oral Oncol 2008, 44:970–974.View ArticlePubMed
            27. Becelli R, Renzi G, Cerulli G, Saltarel A, Perugini M: Von Recklinghausen neurofibromatosis with palatal localization. Diagnostic and surgical problems in two clinical cases. Minerva Stomatol 2002, 51:391–397.PubMed
            28. Meyer U, Wiesmann HP, Berr K, Kubler NR, Handschel J: Cell-based bone reconstruction therapies-principles of clinical approaches. Int J Oral Maxillofac Implants 2006, 21:899–906.PubMed
